Stardog Graviton: AWS Made Easy

Jan 26, 2017, 6 minute read
Stardog Newsletter

Get the latest in your inbox

We think the user experience is crucial, even when dealing with something as complex as a highly available cluster system. So we made Stardog Graviton.

Stardog Graviton compiles to a single binary executable that lives on a client machine and provides a “one-click virtual appliance” installation for Stardog HA Cluster.

It leverages the power of Amazon Web Services to deploy, configure, and launch all of the virtual hardware and software needed for an optimal Stardog cluster deployment. All you have to provide is the AWS account.

TLDR: We made Graviton so that Stardog on AWS would be easy. We made it Apache-licensed so it could be extended to other cloud environments.

Background

Getting a distributed application running can be a challenge. Whether it is to operate a service in production, setup a test environment, or just kick the tires many applications require quite a bit of complicated configuration. Often one needs to know about dependencies like Zookeeper, Kafka, or one of dozens of other amazing, yet nuanced distributed computing subsystems.

Even worse, the hardware (or virtual hardware) should be laid out in specific ways in order to have an optimal deployment. These complications often force customers to become experts in a system far before they are certain that they want to use it in production.

Graviton solves this problem. Read on and I’ll tell you how.

Workflow

Here we describe the typical workflow when using Graviton. It is broken down into steps to give you a better understanding of what is going on under the hood. When Graviton runs, these steps are inferred from the current state and then—unless otherwise specified—automatically run via a single command. If any additional information is required the user will be prompted.

  1. Create the base VM image (AMI). In this step a base AMI is created and associated with your AWS account. A version of Stardog will be burnt into this image along with all of the other software dependencies (Zookeeper, etc). Neither any of your secrets nor your Stardog license key will be associated with it.

  2. Create a deployment. In this step, the size of the Stardog cluster (i.e., the number of nodes) is selected and an Elastic Block Store (EBS) volume is associated with each one. The volume is formatted and the requisite Stardog license is placed on the volume.

  3. Launch the cluster. This step gets the cluster running. It starts Elastic Load Balancers, Auto Scaling Groups, and other AWS components used in the cluster deployment. It runs all the needed discovery and configuration to get the Stardog nodes talking to each other and to the Zookeeper cluster. Each node of both Stardog and Zookeeper will be monitored for health. If they are ever unhealthy for too long, then the VM in question will be killed and restarted.

This sounds like quite a bit more than a “one-click” setup. And it is! There is quite a bit going on behind the scenes, but Graviton just requires the user to simply run a command, answers a few questions, and then be ready to start unifying all the things…

Running Graviton

Because Graviton is a single (Golang!) executable, running it is very easy; however, there are a couple of minor dependencies.

  1. An AWS account and query token pairs that allow access to it. Details on how to create these credentials can be found here. Once you have obtained them you must set environment variables as shown below:
export AWS_ACCESS_KEY_ID=<aws access key>
export AWS_SECRET_ACCESS_KEY=<a valid aws secret key>
  1. The programs terraform and packer must be in your system path. They are also single file executables so this should not be too painful.

  2. A Stardog license. Free trial licenses are available here.

Once those are in place build Graviton as described here and run it. (A single executable beta release will be available soon).

A sample session might look something like this…

$ ./bin/stardog-graviton launch mystardog
What version of stardog are you launching?: 4.2
What is the path to the Stardog release?:
There is no base image for version 4.2.
Do you wish to build one? (yes/no): yes
| Running packer to build the image...
done
AMI Successfully built: ami-0a1d486a
Creating the new deployment mystardog
EC2 keyname (default): stardog
Private key path: /Users/bresnaha/.ssh/stardog
What is the path to your Stardog license?:
| Calling out to terraform to create the volumes...
- Calling out to terraform to stop builder instances...
Successfully created the volumes.
\ Creating the instance VMs...
Successfully created the instance.
Waiting for stardog to come up...
/ Waiting for external health check to pass...
The instance is healthy
Stardog is available here: http://mystardogsdelb-682913646.us-west-1.elb.amazonaws.com:5821
ssh is available here: mystardogbelb-1558182568.us-west-1.elb.amazonaws.com
The instance is healthy
Coordinator:
   10.0.100.6:5821
Nodes:
   10.0.101.168:5821
   10.0.100.243:5821
Success.

Architecture

Ultimately the user of Graviton doesn’t need to know anything about the deployment other than Stardog’s URL, but because it is always helpful to understand how the lower layers work, we will describe the architecture here.

Availability Zones (AZ)

Availability Zones are a concept in AWS that provide some failure protection. The general practice is to have each replicated node in a cluster run in a different AZ and thus if that zone fails the entire application is not affected. When a Graviton deploys a Stardog cluster it distributes all requested Stardog and Zookeeper nodes across all AZs in a given region.

Elastic Block Store (EBS)

One EBS volume is associated with each Stardog node and created in that node’s AZ. The volume has a longer life cycle than the Stardog node. If that node fails and is restarted, or the deployment is paused, then no data is lost.

Elastic Load Balancers (ELB)

ELBs are used in two ways. The first is, as you would expect, as a traditional load balancer. A customer is presented with a URL for the application. That URL points to the load balancer and the load balancer fans requests out to the replicated Stardog nodes.

Because the set of Zookeeper nodes needs to be static, we also use ELBs in a second way. They add a layer of indirection that makes each node in an auto-scaling group reliably addressable, even when their IP addresses change.

Autoscaling Groups (ASG)

ASGs are a crucial part of the deployment. While ASGs can be assigned policies to add or remove nodes from a clustered application, Graviton uses then to simply preserve N nodes. The ASG in conjunction with the ELB monitor the health of each node. If the node is determined to be unhealthy for too long, the virtual machine is terminated and a new one is started in its place. This auto detection allows for the stable, highly-available cluster to be maintained hands-free.

Conclusion

Graviton orchestrates a variety of cloud services in order to deploy and configure a highly-available Stardog cluster. This is a nuanced and complicated process, but to Graviton users it’s a simple CLI app that launches a stable database in the cloud.

A video demonstration of Graviton is available here (note that at the time the video was created we had not yet named the software).

Download Stardog today to start your free 30-day evaluation.
